Dual Band 5g WiFi 6 Sim Card Router
1GE WAN+4GE LAN+1USB 3.0+1RJ11
Support NSA/SA dual-mode networks.
5G Sub 6
Support voip/volte/cs
Send Inquiry
Product Details ofDual Band 5g WiFi 6 Sim Card Router
Dual-Band 5G Sim Card Router WPS Button Wireless Speed 1800Mbps WiFi 6 CPE Router
Model： G536X
Feature:
Next-generation Wi-Fi 6 technology:
Supports the advanced 802.11ax standard, providing an ultra-high-speed dual-band wireless speed of up to 1800Mbps in dense device environments (574Mbps for 2.4GHz and 1201Mbps for 5.8GHz).
Enterprise-Grade 5G Connectivity:
Powered by the premium Qualcomm X55 modem, supporting both 5G SA and NSA architectures with blazing-fast sub-6 GHz download speeds up to 4.2 Gbps.
Robust Multi-Port Routing:
Equipped with 4 Gigabit LAN ports and 1 Gigabit WAN port to deliver a stable, high-speed wired backhaul connection for local networks.
Advanced Hardware Configuration:
Built on a Broadcom quad-core 1.5GHz CPU with 256MB NAND flash and 256MB DDR3L RAM to ensure smooth multi-device management and zero-latency data processing.
Enhanced Network Versatility:
Features an integrated USB 3.0 port and an RJ11 phone jack for voice over IP (VoIP) capabilities, maximizing peripheral utility.
G536X WiFi 6 Dual Band 5g Sim Card Router
Multi-User Connect To Multi-Device Enjoy 5G with ease
●Equipped with Quad-core:1.5GHz.
●All network ports are Gigabit network ports.
●Support space load balancing, upstream and downstream MU-MIMO, and support Beam-forming.
●To realize multi-person and multi-device communication without delay and greatly enhance the signal quality of the user direction.
Seamless Global 5G/4G Band Compatibility:
The router covers comprehensive global frequencies (LTE FDD, TDD, and 5G NR bands), making it an easy-sell product across North American, European, and Asian markets.
Plug-and-play cellular internet:
Solving the delay problem of traditional fixed-line installations. B2B customers only need to insert a 5G SIM card to immediately deploy a high-speed broadband network.
High-Density Device Capacity & Stability:
Leveraging Wi-Fi 6 1024-QAM and DL 4x4 MIMO technologies, it comfortably handles heavy data requests from dozens of simultaneous users without system drops.
Industrial-Grade Security:
Supports the latest WPA3/WPA3-Personal encryption standards alongside built-in firewall, QoS, and VPN features to safeguard sensitive enterprise data.
|
Product Specifications |
||
|
Hardware Parameters |
||
|
Chipset |
BCM6755 + 53134O + QUALCOMM X55 |
|
|
CPU frequency |
Quad-core 1.5GHz |
|
|
Memory |
256MB 16-bit DDR3L |
|
|
Flash |
256M NAND |
|
|
WIFI |
2T2R 2.4GHz 802.11b/g/n/ac/ax, 574Mbps 2T2R 5.8GHz 802.11a/n/ac/ax, 1201Mbps |
|
|
Device Interfaces |
4x RJ45 10M/100M/1000M LAN Ethernet |
|
|
1 x RJ45 10M/100M/1000M WAN Ethernet interface |
||
|
1 x reset button |
||
|
1 x WPS button |
||
|
1 x Power jack |
||
|
1X USB 3.0 |
||
|
1 x RJ11 Phone jack |
||
|
WIFI Antenna |
2 x 3dBi internal 2.4G & 5G dual-band antennas |
|
|
5G/LTE Antenna |
2~7dBi internal antenna |
|
|
WIFI Features |
||
|
Standard |
802.11a/b/g/n/ac/ax |
|
|
2.4G: 2.4~2.4835GHz 5G: ~5.150~5.825 GHz |
||
|
Korea, Japan, ETSI, and FCC channels can be selected |
||
|
Modulation schemes |
OFDM = BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM |
|
|
DSSS = DBPSK, DQPSK, CCK |
||
|
Transfer Rate |
HE20: up to 574Mbps 2.4G+5G HE40: up to 1147 Mbps 2.4 G + 5 G HE80: up to 1201Mbps 5G |
|
|
5G /LTE Features |
||
|
5G/ LTE Standards |
Release 15, Cat. 20 5G NR |
|
|
5G/ LTE Frequency Support |
5G NR SA: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78 5G NR NSA: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78 LTE FDD: B1/B3/B5/B7/B8/B20/B28 LTE TDD: B38/B40/B41/B42/B43 |
|
|
5G/LTE Throughput |
5G SA Sub-6 : DL 4.2Gbps; UL 900Mbps 5G NSA Sub-6: DL 5Gbps; UL 650Mbps LTE: DL 2.0Gbps; UL 150Mbps |
|
|
MIMO |
DL: 4 × 4 UL: 2 × 2 (only support 5G SA) |
|
|
Output Power |
23 dBm ± 2 dBm |
|
G536X WiFi 6 Dual Band 5g Sim Card Router application:
Why choose us
Factory Advantages: Engineering Excellence & Supply Chain Mastery
why choose our products
1. Strategic Chipset Partnerships
Dual-Source Supply: Partnerships with Qualcomm, MediaTek, and ASR ensure chipset availability even during shortages.
Future-Proofing: Support for 5G/LTE Cat6 upgrades and LoRaWAN integrations upon request.
2. Precision Manufacturing & QC
100% Pre-Shipment Testing: 72-hour stress tests (signal stability, thermal performance, VPN throughput).
3-Stage Inspection: PCB assembly → Firmware validation → Final performance audit.
3. Faster Delivery, Lower Costs
15-Day Lead Time: Streamlined production for standard models; 30 days for custom builds.
Cost Efficiency: Eliminate middleman markups - direct factory pricing with 20 %+ savings vs. competitors.
4. Your Success, Our Priority
Dedicated OEM Team: Engineers assist with RFQ, prototyping, and certification (CE/FCC/RoHS).
IP Protection: Strict NDAs and secure firmware encryption for your designs.
Ready to Customize?
Contact us today for a free OEM/ODM consultation and sample request.
Email: info@qs-wifi.com
Our Partners
We have built long-term cooperation with Mediatek, Qualcomm, and Realtek, capably offering stable quality products and fast after-sale service. Main customers include China Mobile, Unicom, Nubia, MTN, JIO, T-Mobile, and AT&T in the USA.
📞 Request a Quote Today
Ready to upgrade your connectivity solutions? Contact us now for a free quote, datasheet, and sample policy. Our team will respond within 24 hours.
[Get a Free Quote] or [Contact Sales] – Fast Response | Flexible MOQ | Global Delivery
